Genuine BMW Throttle Body
Fuel Injection Throttle Body- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orSeries
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
91 Throttle Bodies found
BMW Throttle Body
Part Number: 13548601651$569.76 MSRP: $793.58You Save: $223.82 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy
BMW Throttle Body
Part Number: 13541433414$696.86 MSRP: $884.97You Save: $188.11 (22%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy; Throttle Housing
BMW Throttle Body Compatible
Part Number: 13547502444$475.31 MSRP: $603.62You Save: $128.31 (22%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy; Throttle Body, Throttle Housing
BMW Throttle Body
Part Number: 13548623324$569.76 MSRP: $793.58You Save: $223.82 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy
BMW Throttle Body
Part Number: 13547619008$569.76 MSRP: $793.58You Save: $223.82 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle
BMW Throttle Body
Part Number: 13547597871$512.77 MSRP: $714.21You Save: $201.44 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy
BMW Throttle Body
Part Number: 13547555944$512.77 MSRP: $714.21You Save: $201.44 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy
BMW Throttle Body
Part Number: 13547502445$415.63 MSRP: $523.31You Save: $107.68 (21%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy; Throttle Housing
BMW Air Intake Throttle Body
Part Number: 13547588625$512.77 MSRP: $714.21You Save: $201.44 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle; Throttle Body
BMW Throttle Housing Assy
Part Number: 13548667415$569.76 MSRP: $793.58You Save: $223.82 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Body
BMW Fuel Injection Throttle Body Housing Actuator
Part Number: 13547556118$512.77 MSRP: $714.21You Save: $201.44 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy; Throttle Body, Throttle Housing
BMW Throttle Body
Part Number: 13547618838$569.76 MSRP: $793.58You Save: $223.82 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle
BMW Throttle Body
Part Number: 13547810752$465.48 MSRP: $642.79You Save: $177.31 (28%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle
BMW Throttle Body
Part Number: 13547566243$512.77 MSRP: $714.21You Save: $201.44 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy; Gasket
BMW Throttle Body
Part Number: 13547556119$512.77 MSRP: $714.21You Save: $201.44 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy
BMW Throttle Body
Part Number: 13541439580$512.77 MSRP: $714.21You Save: $201.44 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy
BMW THROTTLE HOUSING ASSY
Part Number: 13549847189$569.76 MSRP: $793.58You Save: $223.82 (29%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Body
BMW Throttle Body
Part Number: 11717804384$439.61 MSRP: $607.06You Save: $167.45 (28%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle; Throttle Valve
BMW Continental Vdo Throttle Housing Assembly
Part Number: 13547506627$451.41 MSRP: $568.35You Save: $116.94 (21%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy; Throttle Body
BMW Throttle Body
Part Number: 13541435709$1284.23 MSRP: $1607.26You Save: $323.03 (21%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Throttle Housing Assy Eml
- Replaces: 13-54-1-745-207, 13-54-1-702-693
| Page 1 of 5 |Next >
1-20 of 91 Results
BMW Throttle Body
The throttle body is the part of the car's air intake system that controls the amount of air flowing into the engine when the accelerator pedal is pressed. Without a fully functioning BMW throttle body, air will not get drawn into the engine, which is necessary to create a proper fuel mixture to ignite combustion. Symptoms of a faulty throttle body include poor shifting of transmission and unsteady engine running.
BMW Throttle Body Parts Questions & Experts Answers
- Q: How to replace the Throttle Body in the N54 six cylinder engine on BMW 335i?A:There is no mechanical link between the accelerator pedal and the throttle plate. The accelerator pedal module at the pedal assembly communicates pedal position directly to the ECM, providing two variable voltage signals via Hall sensors for pedal position and rate of movement. The ECM supplies independent voltage and ground for each Hall sensor, with each receiving 5 volts and ground. As the accelerator pedal moves from rest to full throttle, the sensors generate a variable voltage signal. The output of the Hall sensors is checked for plausibility, with Hall sensor 1 ranging from approximately 0.5 to 4.5 volts and Hall sensor 2 from approximately 0.5 to 2.5 volts. The throttle housing unit is non-adjustable and should be replaced as a complete unit if found faulty. After replacement, a BMW scan tool or equivalent is needed to reset adaptation values, as failure to complete this process correctly will prevent the engine from starting. To replace the throttle housing, switch the ignition off and remove the key, then remove the air filter housing and ducts, followed by the charge air ducts. Disconnect the line at the side of the throttle assembly and the electrical connector underneath it, then remove the fasteners and the throttle housing. Installation is the reverse of removal, ensuring the throttle assembly connector is reattached carefully to avoid twisting, which can damage the harness and connector. Replace the profile gasket between the throttle assembly and intake manifold, and after reinstalling, check for fault codes and reset ECM memory, followed by resetting throttle plate adaptation values according to on-screen directions.
- Q: What steps should be followed to remove the throttle body housing on BMW X5?A:Make sure ignition is switched OFF. Working at the front of the engine compartment above the radiator, remove air intake hood expansion rivets and lift off the hood. Remove the upper engine cover (intake manifold cover). Remove the air filter housing and ducts. Remove EDK throttle housing mounting bolts (arrows) and lift the throttle housing off the intake manifold flange. Prior to reinstallation, be sure to replace the sealing O-ring at the base of the throttle housing.
